Echo 2000VA/1800W Online Rack UPS 2U 230V
ECH2000RMi2U
The Uniti Power Echo 2000VA Online UPS provides true online double-conversion protection in a compact 2U rack-mount design. Ideal for networking, security and IT environments where space is limited but power reliability is critical.
Product Description
The Uniti Power Echo 2000VA / 1800W Online Rack UPS is designed to deliver dependable, professional-grade power protection for modern IT and networking environments. Using true online double-conversion technology, Echo completely isolates connected equipment from mains disturbances, ensuring a continuous supply of clean, stable power at all times.
Unlike line-interactive UPS systems, Echo regenerates the output waveform continuously, protecting sensitive equipment from voltage fluctuations, frequency instability, surges and power interruptions. With a 0ms transfer time, connected systems remain powered without interruption during mains failure, making Echo ideal for critical applications such as network switches, firewalls, security systems and small servers.
The compact 2U short-depth rack-mount design makes the Echo 2000VA particularly well suited to shallow comms racks, wall cabinets and space-restricted installations. Despite its small footprint, the unit delivers a high 0.9 output power factor, providing more usable power for modern IT loads.
A wide input voltage range of 90–275 VAC allows the UPS to remain in online mode for longer during unstable mains conditions, reducing unnecessary battery usage and helping to extend battery life. An intuitive programmable LCD display provides clear, real-time information on load, battery status, input and output values, alarms and operating mode.
For intelligent monitoring and control, the Echo 2000VA includes an intelligent expansion slot compatible with the UPNETG2S network management card, enabling secure remote monitoring via SNMP, Modbus TCP, MQTT or REST API. The UPS also supports WinPower G2 and SPS G2 software for automated shutdown and advanced power management across connected systems.
Quiet operation, robust internal protection features and support for EPO and ROO connections make the Echo range a practical and reliable choice for distributed IT environments where uptime, efficiency and space efficiency are essential.
Backed by a 3-year warranty, the Uniti Power Echo 2000VA Online UPS offers compact, professional online protection for everyday critical power applications.
- True Online Double-Conversion Protection
- Compact 2U Short-Depth Rack Design
- High 0.9 Output Power Factor
- Wide Input Voltage Range
- Advanced Monitoring & Management
Model
ECH2000RMi2U
EAN
7864858488808
Power rating
2000VA/1800W
Input Nominal Voltage
HV: 208/220/230/240VAC
Input Frequency
50/60Hz
Input Voltage Range
HV: 90~275VAC±5VAC
Input Frequency Range
(40~70)±0.5Hz
Input Power Factor
>0.99
Bypass Voltage Range
HV: 187~265V/ (120~275VAC Max)
Input Connection
IEC-C14
Output Power Factor
0.9
Output Nominal Voltage
208V/220/230/240VAC, 230V Default
Output Voltage Regulation
+/-1%
Output Frequency Range
50/60Hz +/-0.05%
Over Load
100%~105% continuous. 60Sec.@105%~130% Rated Load
Voltage Distortion (THDv)
<2% @ linear load
Output Waveform
Pure Sine Wave
Efficiency: Line Mode
90%
Efficiency: Battery Mode
86%
Battery Nominal Voltage
48V
Battery Type
12V/9Ah
Number of Internal Batteries
2
Rated Battery Voltage
48V DC
Charging Current
1A
Recharge Time (to 90%)
5 hours
Transfer Time: Battery Mode <-> Inverter Mode
0ms
Transfer Time: Inverter Mode <-> Bypass Mode
<4ms
Transfer Time: ECO Mode <-> Battery Mode
<10ms
Display
Programmable LCD
Audible Alarm
Yes
Protection Function
AC input or output above or below the range of voltage, overload, over temperature and short circuit protection.
Protection
Discharge, overcharge and overload protection
Product Dimensions WxHxD
439.8 x 88 x 428 mm
Packaged Dimensions WxHxD
570 x 540 x 185 mm
Product Weight
18kg
Packaged Weight
21kg
Operating Temperature
Operating Temperature
Regulation
CE
Noise Level
<50dB (ISO 7779 @ front 1m distance, without buzzer)
IP Rating
IP20
RS232/USB
Yes
External Slot
Yes, for optional UPNETG2S Card
Emergency Power Off
Yes
Standard Warranty
3-year parts/1-year batteries
Full Load
75% Load
50% Load
25% Load
ECH2000RMi2U
3.7 mins
6.3 mins
11.8 mins
20.8 mins
Uniti Power IoT Mobile App
Uniti Power IoT is perfect for businesses with multiple UPS systems spread across different locations, businesses that require remote monitoring and control, and those that want to leverage predictive maintenance to minimise downtime.
Get UPS management and monitoring on the go with the IoT app
 |
 |
WinPower G2 Software
WinPower G2 is a next-generation UPS and PDU monitoring solution, designed to work with the latest UPNETG2S Network Management Card. It provides advanced monitoring, graceful shutdown protection, and multi-platform support – all through a secure web interface.
- Supports Windows, Linux and macOS
- Real-time UPS and PDU monitoring with alert notifications
- Remote server protection (VMware, IPMI, SSH, SPS, NetApp)
- Hierarchical site management and multi-user access control
- Compliant with OWASP cybersecurity standards
Download WinPower G2 Software
Latest Update Date: 19/09/2025
System Protect Software (SPS)
System Protect Software (SPS) is a lightweight shutdown agent that works alongside WinPower G2. It ensures safe system shutdown on client machines during power events — helping prevent data loss and system corruption.
- Installed directly on client PCs or servers
- Executes custom scripts prior to shutdown
- Supports Windows, Linux and macOS (13.3.1 or above recommended)
- Communicates with UPS via WinPower G2 using secure MQTT
- Web interface with power source overview and event logs
Download SPS G2 Software
Latest Update Date: 19/09/2025
-
Model
ECH2000RMi2U
EAN
7864858488808
Power rating
2000VA/1800W
Input Nominal Voltage
HV: 208/220/230/240VAC
Input Frequency
50/60Hz
Input Voltage Range
HV: 90~275VAC±5VAC
Input Frequency Range
(40~70)±0.5Hz
Input Power Factor
>0.99
Bypass Voltage Range
HV: 187~265V/ (120~275VAC Max)
Input Connection
IEC-C14
Output Power Factor
0.9
Output Nominal Voltage
208V/220/230/240VAC, 230V Default
Output Voltage Regulation
+/-1%
Output Frequency Range
50/60Hz +/-0.05%
Over Load
100%~105% continuous. 60Sec.@105%~130% Rated Load
Voltage Distortion (THDv)
<2% @ linear load
Output Waveform
Pure Sine Wave
Efficiency: Line Mode
90%
Efficiency: Battery Mode
86%
Battery Nominal Voltage
48V
Battery Type
12V/9Ah
Number of Internal Batteries
2
Rated Battery Voltage
48V DC
Charging Current
1A
Recharge Time (to 90%)
5 hours
Transfer Time: Battery Mode <-> Inverter Mode
0ms
Transfer Time: Inverter Mode <-> Bypass Mode
<4ms
Transfer Time: ECO Mode <-> Battery Mode
<10ms
Display
Programmable LCD
Audible Alarm
Yes
Protection Function
AC input or output above or below the range of voltage, overload, over temperature and short circuit protection.
Protection
Discharge, overcharge and overload protection
Product Dimensions WxHxD
439.8 x 88 x 428 mm
Packaged Dimensions WxHxD
570 x 540 x 185 mm
Product Weight
18kg
Packaged Weight
21kg
Operating Temperature
Operating Temperature
Regulation
CE
Noise Level
<50dB (ISO 7779 @ front 1m distance, without buzzer)
IP Rating
IP20
RS232/USB
Yes
External Slot
Yes, for optional UPNETG2S Card
Emergency Power Off
Yes
Standard Warranty
3-year parts/1-year batteries
Standards
Our environment policy promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products. We are very proud that our engineering standards and manufacturing practices are in compliance with the EU Reach, EU ROHS and EU WEEE directives.
